threadのお勉強(with python)
ROS x thread x pythonのコードを読みながらthreadの理解、実装方法を学ぶ
python並列化
threading.Thread
multiprocessing.Process
Pythonのマルチスレッド処理:threading, multiprocessing | UX MILK
python x threadについて
Pythonのthreading.Threadとmultiprocessing.Process [ pLog ] 👈イイね!
Python の threading.Lock を試してみる | CUBE SUGAR STORAGE
pythonのcopyについて
8.10. copy — 浅いコピーおよび深いコピー操作 — Python 3.5.3 ドキュメント
https://teratail.com/questions/40811
pythonの値渡し、参照渡しについて
Pythonの値渡しと参照渡し - amacbee's blog
copy – オブジェクトのコピー - Python Module of the Week
pythonのselfについて
和訳 なぜPythonのメソッド引数に明示的にselfと書くのか | TRIVIAL TECHNOLOGIES 4 @ats のイクメン日記
ROS x thread x pythonのコード
jsk_robot/OdometryFeedbackWrapper.py at master · jsk-ros-pkg/jsk_robot · GitHub
self.lock = threading.Lock() ~ def source_odom_callback(self, msg): with self.lock: ~
のようにlockを用いてthread safeを実現
def feedback_odom_callback(self, msg): if not self.odom: return self.feedback_odom = msg with self.lock: # check distribution accuracy nearest_odom = copy.deepcopy(self.odom) nearest_dt = (self.feedback_odom.header.stamp - self.odom.header.stamp).to_sec()
lockした状態のself.odomの中身を深いcopyでnearest_odomに格納。
参考:Python の threading.Lock を試してみる | CUBE SUGAR STORAGE
dynamic_reconfigure/server.py at master · ros/dynamic_reconfigure · GitHub
mutex: 排他制御 http://wa3.i-3-i.info/word13360.html
上記と同じ。lockを使用。
ドローン画像取得 (Erle-Copter, ArduPilot) - Qiita
from threading import Thread, Lock VERBOSE=True import copy mutex = Lock() topic_name = "/camera/image/compressed" class web_video_server: def __init__(self): '''Initialize ros publisher, ros subscriber''' # subscribed Topic self.subscriber = rospy.Subscriber(topic_name, CompressedImage, self.callback, queue_size = 1) if VERBOSE : print "subscribed to " + topic_name def getCompressedImage(self): mutex.acquire(1) result = copy.deepcopy(self.np_arr); mutex.release() return result; def callback(self, ros_data): '''Callback function of subscribed topic. ''' mutex.acquire(1) self.np_arr = ros_data.data; mutex.release()
acquireとreleaseを使用。上記の with self.lock: でも良い。
lockした状態のself.np_arrの中身を深いcopyでresultに格納。
画像をgetするとき、callbackで更新するときそれぞれlockしている。
robot_blockly/image_server.py at master · erlerobot/robot_blockly · GitHub
http://files.cnblogs.com/files/cv-pr/ros_by_example_vol2_indigo.pdf
全体参考
Pythonで学ぶ 基礎からのプログラミング入門 (33) マルチスレッド処理を理解しよう(後編) | マイナビニュース
機械学習のお勉強(モデルの評価とパラメータのチューニング)
教科書
Data準備
import pandas as pd import urllib try: df = pd.read_csv('https://archive.ics.uci.edu/ml/machine-learning-databases' '/breast-cancer-wisconsin/wdbc.data', header=None) except urllib.error.URLError: df = pd.read_csv('https://raw.githubusercontent.com/rasbt/' 'python-machine-learning-book/master/code/' 'datasets/wdbc/wdbc.data', header=None) if Version(sklearn_version) < '0.18': from sklearn.cross_validation import train_test_split else: from sklearn.model_selection import train_test_split X_train, X_test, y_train, y_test = \ train_test_split(X, y, test_size=0.20, random_state=1)
PipeLine
パイプラインを使うと変換を一つにまとめて行うことができる。
以下はスケーリング、主成分分析、ロジスティック回帰をパイプラインで繋いで実行している。
from sklearn.preprocessing import StandardScaler from sklearn.decomposition import PCA from sklearn.linear_model import LogisticRegression from sklearn.pipeline import Pipeline pipe_lr = Pipeline([('scl', StandardScaler()), ('pca', PCA(n_components=2)), ('clf', LogisticRegression(random_state=1))]) pipe_lr.fit(X_train, y_train) print('Test Accuracy: %.3f' % pipe_lr.score(X_test, y_test)) y_pred = pipe_lr.predict(X_test)
結果
Test Accuracy: 0.947
モデルの評価
モデル選択:未知のデータへの予測性能を上げるため、パラメータ設定のチューニングや比較を行う。ここでのチューニングパラメータをハイパーパラメータということがある。
ホールドアウト法
ホールドアウト法でのモデル選択での効果を上げるには、データセットを
の3つにわける。
問題はデータのサンプル数や分割の仕方に影響を受けることである。
k分割交差検証
非復元抽出を用いて、トレーニングデータセットをk個に分割し、k-1個をトレーニングに使用し、1個をテストに使用する。一般的には10分割することが多いが、小さいデータセットの場合などは1個抜き交差検証などが使用される。
非復元抽出:選んだ対象をサンプルに戻さない
層化k分割交差検証
各クラスの比率が均等でない時に、評価のバイアスとバリアンスが改善される。
import numpy as np if Version(sklearn_version) < '0.18': from sklearn.cross_validation import StratifiedKFold else: from sklearn.model_selection import StratifiedKFold if Version(sklearn_version) < '0.18': kfold = StratifiedKFold(y=y_train, n_folds=10, random_state=1) else: kfold = StratifiedKFold(n_splits=10, random_state=1).split(X_train, y_train) scores = [] for k, (train, test) in enumerate(kfold): pipe_lr.fit(X_train[train], y_train[train]) score = pipe_lr.score(X_train[test], y_train[test]) scores.append(score) print('Fold: %s, Class dist.: %s, Acc: %.3f' % (k+1, np.bincount(y_train[train]), score)) print('\nCV accuracy: %.3f +/- %.3f' % (np.mean(scores), np.std(scores)))
結果
CV accuracy: 0.950 +/- 0.029
skkearnで簡略化すると
if Version(sklearn_version) < '0.18': from sklearn.cross_validation import cross_val_score else: from sklearn.model_selection import cross_val_score scores = cross_val_score(estimator=pipe_lr, X=X_train, y=y_train, cv=10, n_jobs=1) #CPUのコア数を指定できる print('CV accuracy scores: %s' % scores) print('CV accuracy: %.3f +/- %.3f' % (np.mean(scores), np.std(scores)))
結果
CV accuracy scores: [ 0.89130435 0.97826087 0.97826087 0.91304348 0.93478261 0.97777778 0.93333333 0.95555556 0.97777778 0.95555556] CV accuracy: 0.950 +/- 0.029
参考
http://www.jmlr.org/papers/volume6/markatou05a/markatou05a.pdf
Improvements on Cross-Validation: The .632+ Bootstrap Method on JSTOR
アルゴリズムの診断
学習曲線
サンプルサイズの値の変化による評価
バイアスが高い:トレーニングと検証の正解率が低い
バリアンスが高い:トレーニングと交差検証の精度に大きな差がある
import matplotlib.pyplot as plt if Version(sklearn_version) < '0.18': from sklearn.learning_curve import learning_curve else: from sklearn.model_selection import learning_curve pipe_lr = Pipeline([('scl', StandardScaler()), ('clf', LogisticRegression(penalty='l2', random_state=0))]) train_sizes, train_scores, test_scores =\ learning_curve(estimator=pipe_lr, X=X_train, y=y_train, train_sizes=np.linspace(0.1, 1.0, 10), cv=10, n_jobs=1) train_mean = np.mean(train_scores, axis=1) train_std = np.std(train_scores, axis=1) test_mean = np.mean(test_scores, axis=1) test_std = np.std(test_scores, axis=1) plt.plot(train_sizes, train_mean, color='blue', marker='o', markersize=5, label='training accuracy') plt.fill_between(train_sizes, train_mean + train_std, train_mean - train_std, alpha=0.15, color='blue') plt.plot(train_sizes, test_mean, color='green', linestyle='--', marker='s', markersize=5, label='validation accuracy') plt.fill_between(train_sizes, test_mean + test_std, test_mean - test_std, alpha=0.15, color='green') plt.grid() plt.xlabel('Number of training samples') plt.ylabel('Accuracy') plt.legend(loc='lower right') plt.ylim([0.8, 1.0]) plt.tight_layout() # plt.savefig('./figures/learning_curve.png', dpi=300) plt.show()
結果
fill_betweenによって標準偏差に色が塗られている
検証曲線
モデルのパラメータの変化に対する評価
if Version(sklearn_version) < '0.18': from sklearn.learning_curve import validation_curve else: from sklearn.model_selection import validation_curve param_range = [0.001, 0.01, 0.1, 1.0, 10.0, 100.0] train_scores, test_scores = validation_curve( estimator=pipe_lr, X=X_train, y=y_train, param_name='clf__C', param_range=param_range, cv=10) train_mean = np.mean(train_scores, axis=1) train_std = np.std(train_scores, axis=1) test_mean = np.mean(test_scores, axis=1) test_std = np.std(test_scores, axis=1) plt.plot(param_range, train_mean, color='blue', marker='o', markersize=5, label='training accuracy') plt.fill_between(param_range, train_mean + train_std, train_mean - train_std, alpha=0.15, color='blue') plt.plot(param_range, test_mean, color='green', linestyle='--', marker='s', markersize=5, label='validation accuracy') plt.fill_between(param_range, test_mean + test_std, test_mean - test_std, alpha=0.15, color='green') plt.grid() plt.xscale('log') plt.legend(loc='lower right') plt.xlabel('Parameter C') plt.ylabel('Accuracy') plt.ylim([0.8, 1.0]) plt.tight_layout() # plt.savefig('./figures/validation_curve.png', dpi=300) plt.show()
結果
C = 0.1あたりが最適だと見てとれる
グリッドサーチによるチューニング
機械学習にはデータから学習されるパラメータと個別に最適されるパラメータがある。後者はハイパーパラメータと呼ばれ、チューニングパラメータである。
グリッドサーチ:しらみつぶしの網羅的探索手法
from sklearn.svm import SVC if Version(sklearn_version) < '0.18': from sklearn.grid_search import GridSearchCV else: from sklearn.model_selection import GridSearchCV pipe_svc = Pipeline([('scl', StandardScaler()), ('clf', SVC(random_state=1))]) param_range = [0.0001, 0.001, 0.01, 0.1, 1.0, 10.0, 100.0, 1000.0] param_grid = [{'clf__C': param_range, 'clf__kernel': ['linear']}, {'clf__C': param_range, 'clf__gamma': param_range, 'clf__kernel': ['rbf']}] gs = GridSearchCV(estimator=pipe_svc, param_grid=param_grid, scoring='accuracy', cv=10, n_jobs=-1) gs = gs.fit(X_train, y_train) print(gs.best_score_) print(gs.best_params_) clf = gs.best_estimator_ clf.fit(X_train, y_train) print('Test accuracy: %.3f' % clf.score(X_test, y_test))
結果
0.978021978022 {'clf__C': 0.1, 'clf__kernel': 'linear'} Test accuracy: 0.965
欠点としては、考えられるすべての組み合わせについて評価するためコストが高くつく。
sk-learnにはRandomizedSearchCVというランダムサーチの手法を用いることができる。
入れ子式の交差検証によるアルゴリズムの選択
5x2交差検証の例
gs = GridSearchCV(estimator=pipe_svc, param_grid=param_grid, scoring='accuracy', cv=2) # Note: Optionally, you could use cv=2 # in the GridSearchCV above to produce # the 5 x 2 nested CV that is shown in the figure. scores = cross_val_score(gs, X_train, y_train, scoring='accuracy', cv=5) print('CV accuracy: %.3f +/- %.3f' % (np.mean(scores), np.std(scores)))
結果
CV accuracy: 0.965 +/- 0.025
決定木分類器
from sklearn.tree import DecisionTreeClassifier gs = GridSearchCV(estimator=DecisionTreeClassifier(random_state=0), param_grid=[{'max_depth': [1, 2, 3, 4, 5, 6, 7, None]}], scoring='accuracy', cv=2) scores = cross_val_score(gs, X_train, y_train, scoring='accuracy', cv=5) print('CV accuracy: %.3f +/- %.3f' % (np.mean(scores), np.std(scores)))
結果
CV accuracy: 0.921 +/- 0.029
SVMのほうが性能が良いことがわかる
様々な性能評価指標
正解率以外にも様々な評価する指標が存在する
混同行列
真陽陰性(TP,TN)、偽陽陰性(FP,FN)を表現する行列
真偽:予測があたったかどうか
陽陰:予測されたクラス
ex: 偽陽性は予測は陽だが間違えた
sklearn -> confusion_matrix(y_true=
で作成できる
from sklearn.metrics import confusion_matrix pipe_svc.fit(X_train, y_train) y_pred = pipe_svc.predict(X_test) confmat = confusion_matrix(y_true=y_test, y_pred=y_pred) print(confmat) fig, ax = plt.subplots(figsize=(2.5, 2.5)) ax.matshow(confmat, cmap=plt.cm.Blues, alpha=0.3) for i in range(confmat.shape[0]): for j in range(confmat.shape[1]): ax.text(x=j, y=i, s=confmat[i, j], va='center', ha='center') plt.xlabel('predicted label') plt.ylabel('true label') plt.tight_layout() # plt.savefig('./figures/confusion_matrix.png', dpi=300) plt.show()
結果
誤分類率、正解率
ERR = (FP + FN) / (FP + FN + TP + TN)
ACC = 1 - ERR
真陽性、偽陽性
不均衡なクラスの問題に役立つ指標
FPR = FP / (FP + TN)
TPR = TP / (FN + TP)
適合率、再現率
PRE = TP / (TP + FP)
REC = TP / (FN + TP)
F1スコア
適合率や再現率を組み合わせた評価指標。よく使用される。
F1 = 2 * (PRE * REC) / (PRE + REC)
sklearnでの評価手法の実装
from sklearn.metrics import precision_score, recall_score, f1_score print('Precision: %.3f' % precision_score(y_true=y_test, y_pred=y_pred)) print('Recall: %.3f' % recall_score(y_true=y_test, y_pred=y_pred)) print('F1: %.3f' % f1_score(y_true=y_test, y_pred=y_pred))
結果
Precision: 0.976 Recall: 0.952 F1: 0.964
sk-learnではmake_scorerで自作の性能評価関数を作成できる
from sklearn.metrics import make_scorer scorer = make_scorer(f1_score, pos_label=0) c_gamma_range = [0.01, 0.1, 1.0, 10.0] param_grid = [{'clf__C': c_gamma_range, 'clf__kernel': ['linear']}, {'clf__C': c_gamma_range, 'clf__gamma': c_gamma_range, 'clf__kernel': ['rbf']}] gs = GridSearchCV(estimator=pipe_svc, param_grid=param_grid, scoring=scorer, cv=10, n_jobs=-1) gs = gs.fit(X_train, y_train) print(gs.best_score_) print(gs.best_params_)
結果
0.982798668208 {'clf__C': 0.1, 'clf__kernel': 'linear'}
ROC曲線
受信者操作特性:性能に基づいて分類モデルを選択するための便利なツール
AUC:曲面下面積
from sklearn.metrics import roc_curve, auc from scipy import interp pipe_lr = Pipeline([('scl', StandardScaler()), ('pca', PCA(n_components=2)), ('clf', LogisticRegression(penalty='l2', random_state=0, C=100.0))]) X_train2 = X_train[:, [4, 14]] if Version(sklearn_version) < '0.18': cv = StratifiedKFold(y_train, n_folds=3, random_state=1) else: cv = list(StratifiedKFold(n_splits=3, random_state=1).split(X_train, y_train)) fig = plt.figure(figsize=(7, 5)) mean_tpr = 0.0 mean_fpr = np.linspace(0, 1, 100) all_tpr = [] for i, (train, test) in enumerate(cv): probas = pipe_lr.fit(X_train2[train], y_train[train]).predict_proba(X_train2[test]) fpr, tpr, thresholds = roc_curve(y_train[test], probas[:, 1], pos_label=1) mean_tpr += interp(mean_fpr, fpr, tpr) mean_tpr[0] = 0.0 roc_auc = auc(fpr, tpr) plt.plot(fpr, tpr, lw=1, label='ROC fold %d (area = %0.2f)' % (i+1, roc_auc)) plt.plot([0, 1], [0, 1], linestyle='--', color=(0.6, 0.6, 0.6), label='random guessing') mean_tpr /= len(cv) mean_tpr[-1] = 1.0 mean_auc = auc(mean_fpr, mean_tpr) plt.plot(mean_fpr, mean_tpr, 'k--', label='mean ROC (area = %0.2f)' % mean_auc, lw=2) plt.plot([0, 0, 1], [0, 1, 1], lw=2, linestyle=':', color='black', label='perfect performance') plt.xlim([-0.05, 1.05]) plt.ylim([-0.05, 1.05]) plt.xlabel('false positive rate') plt.ylabel('true positive rate') plt.title('Receiver Operator Characteristic') plt.legend(loc="lower right") plt.tight_layout() # plt.savefig('./figures/roc.png', dpi=300) plt.show()
AUCの計算
pipe_lr = pipe_lr.fit(X_train2, y_train) y_labels = pipe_lr.predict(X_test[:, [4, 14]]) y_probas = pipe_lr.predict_proba(X_test[:, [4, 14]])[:, 1] # note that we use probabilities for roc_auc # the `[:, 1]` selects the positive class label only from sklearn.metrics import roc_auc_score, accuracy_score print('ROC AUC: %.3f' % roc_auc_score(y_true=y_test, y_score=y_probas)) print('Accuracy: %.3f' % accuracy_score(y_true=y_test, y_pred=y_labels))
多クラス分類の性能指標
sk-learnでは以下が実装されている
マクロ平均法
マイクロ平均法
マイクロ平均
各インスタンスまたは予測を平等に重みつけしたいとき
PREmicro = (TP1 + ... + TPk) / (TP1 + ... + TPk + FP1 + ... + FPk)
マクロ平均
最も出現するクラスラベルに過度に影響を受けることがないよう評価したいとき
PREmacro = (PRE1 + ... + PREk) / k
pre_scorer = make_scorer(score_func=precision_score, pos_label=1, greater_is_better=True, average='micro')
proxyのお勉強
プロキシとは、企業などの内部ネットワークとインターネットの境界にあり、内部のコンピュータの「代理」(proxy)としてインターネット上のコンピュータへ接続を行うコンピュータのこと。また、そのような機能を持つサーバソフトウェア。
http://wa3.i-3-i.info/word1752.html
わかりやすい参考
proxy環境下の設定(ubuntu 14.04) - Qiita
$ export https_proxy="http://username:password@your.proxy.address:proxy.port/"
環境変数の引き継ぎ
sudo -E apt-get ~
環境変数の削除
$ unset https_proxy
avahiのお勉強
avahi
Avahi(アバヒ)は、Zeroconfのフリーソフトウェア実装であり、マルチキャストDNS/DNS-SD サービスディレクトリのためのシステムを含む。
avahi-daemon - The Avahi mDNS/DNS-SD daemon - Linux Man Pages (8)
[Ubuntu] Avahiのコマンド一覧 - Life with IT
hostnameの重複を許す
enable-reflector=yes
ホスト名のコンフリクトについて
avahi daemonは、起動時にはコンフリクトメッセージを出さずにホスト名を取得します。 また、一度ホスト名を決定した後は、ホスト名をキャッシュし、ifup/downで同じホスト名を使い続けるので 一度ホスト名が決まってしまえば 下記のような場合を除いてifup/downで衝突は起きません。
hostname conflict with avahi (post 3.0) · Issue #1426 · pi-hole/pi-hole · GitHub
avahi-daemonのシステムログの内容について | アットマークテクノ ユーザーズサイト
linux - Avahi Hostname Resolution: Is it caching somewhere? - Stack Overflow
How do I flush out the DNS resolver cache? - Ask Ubuntu
Re: [DNG] how to clear DNS cache
-> /etc/resolv.conf
DNSキャッシュのクリア
How To: Flush Your Local DNS Cache – Liquid Web Knowledge Base
sudo service dns-clean restart
/etc/hosts
127.0.1.1 robonchu
/etc/nsswitch.conf
名前解決の参照順位が設定されている
hosts: files mdns4_minimal [NOTFOUND=return] dns nis
mdns:マルチキャストDNS
JVNVU#98589419: マルチキャスト DNS (mDNS) 実装が外部からのユニキャストクエリに応答する問題
nis
UNIXコマンド、シェルスクリプトのお勉強
- Unix Command
- vim
- link
- user, group
- permission
- command make
- pathを通す
- 管理者user
- chown
- text operation
- redirection,pipe
- ワイルドカード
- find,xargs
- ブレース展開
- shell
- ディレクトリ
- 参考
Unix Command
mkdir app{1..40}
clear
cd
rmdir
ls
cat text.txt : 全文表示
less text.txt
- /<検索したいワード>
mv
ctrl+r :直近のコマンドを探す
history : 履歴を呼び出す
!<historyで出たID> : 履歴のコマンドを実行
cd !$ : commadに渡した最後の文字を利用する
!pw : pwから始まる直近のコマンドを実行できる
man ls
mkdir --help
touch
vim
vi
command mode: esc key
保存->:w
抜ける->:q
編集モード: i
link
ln -s
unlink
user, group
cat /etc/passwd
cat /etc/group
groups
permission
rwxrw-r--
rwx : user
rw- : group
r-- : other
read,write,execute
chmod g+x
chmod go+x
chmod a-x
rwx : 4+2+1 = 7
rw- : 4+2+0 = 6
r-- : 4+0+0 = 4
chmod 764
command make
type cat
vi hi
#!/bin/bash echo "hi!"
chmod u+x hi
./hi
pathを通す
- echo $PATH
ここから探してコマンドを実行する
printenv
export PATH=/
:$PATH hi
which hi
管理者user
ls -l /var/log/message
cat !$
su -l : root userに切り替える
cat /var/log/messages
sudo cat /var/log/messages
chown
cp /var/log/messages .
sudo !!
cat messages
sudo chown
: messages cat messages
text operation
wc -l messages
head messages
head -n 3 messages
tail -n 3 messages
grep 'etc' messages
redirection,pipe
echo "date" > cmd.txt
cat cmd.txt
echo "free" >> cmd.txt
bash < cmd.txt
bash < cmd.txt > result.txt
cat result.txt
ワイルドカード
ls /etc/*.conf
ls /etc/c??.*
find,xargs
find /etc -name "http*"
sudo !!
find /etc -name "http*" -type f -exec wc -l {} +
find /etc -name "http*" -type f | xargs wc -l
ブレース展開
echo {a,b,c}
echo {1..10}
echo {1..10}{a..g}
make test && cd test
mkdir app{1..5}
touch app{1..5}/test{1..3}{.txt,.jpeg,.gif}
rm app{1..5}/test{1..3}{.jpeg,.gif}
shell
./hello a aa aaa
#!/bin/bash # comment # $1, $2, ... echo "hello $1" echo $0 # ./hello echo $# # 3 echo $@ # $* a aa aaa greeting="hello" #space入れちゃダメ! echo "hello world" echo 'hello world' echo "hello robot" echo "$greeting world" echo '$greeting world' #展開されない echo "${greeting}robot" echo "foo"; echo "bar"
ディレクトリ
bin:実行コマンド
etc:設定
home:各ユーザー
sbin:システム管理用のコマンド
usr:一般的なアプリケーション
var:システムのログファイル
参考
Dockerのお勉強
概要
Build once, run anywhere
Docker - Build, Ship, and Run Any App, Anywhere
VagrantでUbuntuを用意する
Vagrantは、開発環境の構築と共有を簡単に行うためのツールです。どこでも同じ環境を再現できるように仮想マシン環境を管理する機能と、Atlasを通して共有する仕組みが提供されています。
開発環境の構築・共有を簡単にするVagrant入門 | Think IT(シンクイット)
A list of base boxes for Vagrant - Vagrantbox.es
Official Ubuntu 14.04 daily Cloud Image amd64 (Development release, No Guest Additions) をインストール
sudo apt-get install vagrant vagrant box add trusty64 https://cloud-images.ubuntu.com/vagrant/trusty/current/trusty-server-cloudimg-amd64-vagrant-disk1.box sudo apt-get install virtualbox mkdir Docker && cd Docker vagrant init vagrant up vagrant ssh
こうするとvagrant user で以下のように起動できていることが確認できる
vagrant@vagrant-ubuntu-trusty-64:~$
Dockerで環境構築
docker-ceのインストール
Get Docker CE for Ubuntu | Docker Documentation
UbuntuにDocker CEをインストールする - Qiita
確認:sudo docker --version
imageの操作
sudo docker search centos sudo docker pull centos sudo docker images sudo docker inspect centos:latest sudo docker rmi <id> sudo docker run centos echo "hello world" sudo docker ps -a -n=5 (a:過去を表示、-n:最新5つ) sudo docker rm <id> sudo docker run -d centos free -s 3 sudo docker ps sudo docker logs <id> sudo docker attach --sig-proxy=false <id> sudo docker kill <id> sudo docker start <id> sudo docker run -i -t centos /bin/bash (-i:インタラクティブ, -t:ターミナル) touch hello.txt exit sudo docker ps -a sudo docker commit <id> robonchu/hello sudo docker images sudo docker run -i -t robonchu/hello /bin/bash ls
これでhello.txtがあることが確認できる
docker build
emacs -nw Dockerfile
FROM centos MAINTAINER robonchu <robonchu@gmail.com> # RUN: build時に実行 RUN echo "now building..." # CMD: run時に実行 # CMD echo "now running..." CMD ["echo", "now running..."]
以下でrun commitの動作、つまりimageからcontainer、そして、imageにする動作が行えることが確認できる
sudo docker build -t robonchu/echo . sudo docker run robonchu/echo
さらに emacs -nw Dockerfile
RUN yum install -y httpd ADD ./index.html /var/www/html/ EXPOSE 80 CMD ["/usr/sbin/httpd", "-D", "FOREGROUND"]
emacs -nw index.html
<html> hello from Docker! </html>
sudo docker build -t robonchu/httpd . sudo docker run -p 8080:80 -d robonchu/httpd
ウェブページを開いて、192.168.55.44:8080でhello from Docker!がでていることを確認
Imageをpush
上記の登録が必要
sudo docker login sudo docker push robonchu/httpd
参考
https://dotinstall.com/lessons/basic_docker
Dockerでよく使うコマンドまとめ | 酒と涙とRubyとRailsと
さわって理解するDocker入門 第1回 | オブジェクトの広場
機械学習のお勉強(自作データセットでCNN by pytorch)
- Pytorch tutorial
- DataSetの作成
- DataLoader
- Model Definition
- Training
- total evaluation
- each class evaluation
CNNを用いた簡単な2class分類をしてみる
Pytorch tutorial
Training a Classifier — PyTorch Tutorials 1.4.0 documentation
Transfer Learning for Computer Vision Tutorial — PyTorch Tutorials 1.4.0 documentation
Writing Custom Datasets, DataLoaders and Transforms — PyTorch Tutorials 1.4.0 documentation
DataSetの作成
https://download.pytorch.org/tutorial/hymenoptera_data.zip
ここからアリさんとハチさんのデータセットをダウンロード
ディレクトリ構成
train
- ants
- bees
val
- ants
- beets
となっている。
このように自分で作ったデータセットを用意してあげる。
DataLoader
# -*- coding: utf-8 -*- import torch from torchvision import transforms, datasets # 取り込んだデータに施す処理を指定 data_transform = transforms.Compose([ transforms.RandomSizedCrop(224), transforms.RandomHorizontalFlip(), transforms.ToTensor(), transforms.Normalize(mean=[0.485, 0.456, 0.406], std=[0.229, 0.224, 0.225]) ]) # train data読み込み hymenoptera_dataset = datasets.ImageFolder(root='hymenoptera_data/train', transform=data_transform) dataset_loader = torch.utils.data.DataLoader(hymenoptera_dataset, batch_size=4, shuffle=True, num_workers=4) # test data読み込み hymenoptera_testset = datasets.ImageFolder(root='hymenoptera_data/val', transform=data_transform) dataset_testloader = torch.utils.data.DataLoader(hymenoptera_testset, batch_size=4, shuffle=False, num_workers=4) classes = ('ants', 'bees')
データセットの形は
for i, data in enumerate(dataset_loader, 0): inputs, labels = data print inputs.size() print labels.size() -> (4L, 3L, 224L, 224L) (4L,)
となる。
自作transformsの使い方
class Crop(object): """Crop the image. Args: left_up (tuple): Desired crop left up position. right_down (tuple): Desired crop right down position. """ def __init__(self, left_up, right_down): self._left_up = left_up self._right_down = right_down def __call__(self, img): image = img.crop((self._left_up[0], self._left_up[1], self._right_down[0], self._right_down[1])) return image
これを以下のように使用すれば良い
data_transform = transforms.Compose([ transforms.Scale(224), Crop((50,100),(100,200)), transforms.RandomHorizontalFlip(), transforms.ToTensor(), transforms.Normalize(mean=[0.5, 0.5, 0.5], std=[0.5, 0.5, 0.5]) ])
PILの使い方
pytorchの画像の読み込み、処理はPILを使っている
Model Definition
from torch.autograd import Variable import torch.nn as nn import torch.nn.functional as F class Net(nn.Module): def __init__(self): super(Net, self).__init__() self.conv1 = nn.Conv2d(3, 6, 5) self.pool = nn.MaxPool2d(2, 2) self.conv2 = nn.Conv2d(6, 16, 5) self.fc1 = nn.Linear(16 * 53 * 53, 120) # (((224 - 4) / 2 ) - 4) / 2 = 53 self.fc2 = nn.Linear(120, 84) self.fc3 = nn.Linear(84, 2) def forward(self, x): x = self.pool(F.relu(self.conv1(x))) x = self.pool(F.relu(self.conv2(x))) x = x.view(-1, 16 * 53 * 53) x = F.relu(self.fc1(x)) x = F.relu(self.fc2(x)) x = self.fc3(x) return x net = Net()
Training
import torch.optim as optim criterion = nn.CrossEntropyLoss() optimizer = optim.SGD(net.parameters(), lr=0.001, momentum=0.9) for epoch in range(1): # loop over the dataset multiple times running_loss = 0.0 for i, data in enumerate(dataset_loader, 0): # get the inputs inputs, labels = data # wrap them in Variable inputs, labels = Variable(inputs), Variable(labels) # zero the parameter gradients optimizer.zero_grad() # forward + backward + optimize outputs = net(inputs) loss = criterion(outputs, labels) loss.backward() optimizer.step() # print statistics running_loss += loss.data[0] if i % 10 == 9: # print every 10 mini-batches print('[%d, %5d] loss: %.3f' % (epoch + 1, i + 1, running_loss / 10)) running_loss = 0.0 print('Finished Training')
total evaluation
correct = 0 total = 0 for data in dataset_testloader: images, labels = data outputs = net(Variable(images)) _, predicted = torch.max(outputs.data, 1) total += labels.size(0) correct += (predicted == labels).sum() print('Accuracy of the network on the test images: %d %%' % ( 100 * correct / total))
each class evaluation
class_correct = list(0. for i in range(2)) class_total = list(0. for i in range(2)) for data in dataset_testloader: images, labels = data outputs = net(Variable(images)) _, predicted = torch.max(outputs.data, 1) c = (predicted == labels).squeeze() try: for i in range(4): label = labels[i] class_correct[label] += c[i] class_total[label] += 1 except: break for i in range(2): print('Accuracy of %5s : %2d %%' % ( classes[i], 100 * class_correct[i] / class_total[i]))
